Description
Specification
| Update | 1 July 2023 | |
| ST11-U SPEC | ||
| ITEM | DESCRIPTION | DETAIL |
| OS | Windows 11 Pro | |
| CPU | Intel I5-1235U 10 cores, 12 threads/basic frequency 1.3GHz, turbo 4.4GHz /power consumption 15W |
I7-1255U Optional 10 cores, 12 threads/basic frequency 1.7GHz, turbo 4.7GHz/power consumption 15W |
| GPU | Intel® Iris® Xe Graphics 80EU | I7: Intel® Iris® Xe Graphics 96EU |
| RAM/ROM | I5： RAM：8GB/16GB（Maximum 64GB） ROM: 128GB/256GB/512GB I7： RAM：16GB/32GB（Maximum 64GB） ROM: 128GB/256GB/512GB |
RAM： LPDDR5 496 Ball ROM： M.2 2242 SATA（C500） |
| LCD | 10.1 inch; 1200*1920; 450nits | |
| Touch Screen | 10 Point Touch | Support stylus |
| Camera | Front: 5MP; Rear: 8MP | |
| Power | 6000mAh，7.6V lithium battery (45.6Wh) | Charging time: 2H30min Usage time: 5H30min (50% volume, 60% brightness, playing local 1080P video) Standby time: about 6 days(screen off standby) |
| DC4.0, 12V DC input | Supports Type-C 65W fast charging | |
| WWAN | FDD_LTE: B1/B2/B3/B4/B5/B7/B8/B28 TDD_LTE: B40 WCDMA: B1/B2/B4/B5/B8 GSM: B2/B3/B5/B8 |
Module: SLM770A (EC25-AUX in North America) |
| GPS | BDS, GPS, GLONASS | |
| WIFI | 802.11a/b/g/n/ac/ax Wireless Internet Wireless AP ( Mobile AP )2.4G, 5G |
Intel® Wi-Fi 6 AX201 (WiFi/Bluetooth 2-in-1) |
| BLUETOOTH | 5.2 Version | |
| NFC | 13.56 MHz, Distance: 1-3cm | ISO14443 TYPE A |
| MIC | Sensitivity: -32±2d Output Impedance: 2.2kΩx1 |
|
| SPEAKER | 8Ω 1.5 Watt | |
| Sensor | 1. Light Sensor 2. Acceleration Sensor 3. G-Sensor |
|
| Size | 273*172*20cm | |
| Weight | 1190±50g | |
| Language | Multi language | |
| Interface In/Out Port |
1. DC*1; 4.0*15mm 2. HDMI Type A x1,Audio and video output 3. USB Type_A：USB3.2 Gen1 x2 4. USB Type_C：USB3.2 Gen1 x1(type-c include PD, DP, Data transmission, Charging) 5. Earphone：∮3.5mm headphone jack x1 6. RJ45：Support Gigabit Ethernet 7. RS232：Standard DB9 |
Bottom pogopin: USB 2.0; Charging; RS232 Back pogopin: USB 2.0; RS232 |
| Button | V+ -, Power, "F" for Barcode Scan | Customized Button: P, H (Default No Functionality) |
| 1D/2D Barcode | Optional | Honeywell N4680 Optional |
| UHF RFID | M-500 Optional | American standard M-500 (902Mhz – 928Mhz) External: card reading distance of 3-5M |
| European standard M-500(865MHz – 868MHz) External: Card reading distance of 3-5M |
||
| M-301 Optional | American standard M-301 (902Mhz – 928Mhz) External: card reading distance of 5-8M |
|
| European standard M-301(865MHz – 868MHz) External: Card reading distance of 5-8M |
||
| Fingerprint | Optional | AFM60 Optional |
| High Precision GPS | Optional | UM960 |
| Accessories | 1. Blue Box 2. DC Charger (12V 4A) 3. Carry strap 4. Screw 5. Wrist strap |
Optional: 1. Docking Station 2. Car Holder 3. Car Docking |
| Multi-Media (Hardware Decoding) |
1. Photo Viewer: BMP, JPG, GIF, PNG 2. Video Format: MEPG 1/2/4,H.263/H.264, RMVB,WMV/VC-1,MVC,AVS,MJPEG. (UP TO 1080P) 3. Audio Format: MP3,WMA,WAV,OGG,FLAC,ALAC, APE,AAC,AC-3,DTS (need license) |
|
| Proof Degree | Anti-dust & Waterproof IP54 Dropping Resistance 1.2 meters |
|
| Certification | 1. MIL-STD-810G 2. ISO-9001 3. CE, FCC, 3C |
|
| Temperature | Storage Temperature: -25 °C to 80 °C Operation Temperature: -20 °C to 55 °C |
