SINSOOLE SM5 Rugged Phone

Core Specifications & Performance

• Operating System:
  Runs on Android 11.0, providing a stable and user – friendly platform. Android 11 offers a vast ecosystem of applications, enabling seamless integration with different software for enhanced productivity. Whether it’s for communication, data collection, or running specialized applications, Android 11 ensures a smooth user experience.
• Processor:
  Powered by the MTK MT6765 octa – core processor. With 4 Cortex – A53 cores running at 1.8GHz and 4 at 2.3GHz, it can handle multitasking and basic data processing tasks efficiently. This makes it suitable for running multiple applications simultaneously, such as inventory management software and communication tools.
• Graphics:
  Features the IMG PowerVR GE8320 GPU, which can handle graphical tasks such as video playback, graphical user interfaces, and light – weight gaming or augmented reality applications. It ensures a smooth visual experience for users, whether they are viewing product images, watching training videos, or using applications with graphical elements.
• Memory/Storage:
  • Base configuration: 4GB of RAM and 64GB of ROM.
  • Optional upgrade: 6GB of RAM and 128GB of ROM. This gives users the option to choose a setup that best suits their multitasking and storage needs. For example, users who need to run multiple applications and store a large amount of data may opt for the 6GB/128GB version, while those with more basic requirements can choose the 4GB/64GB configuration.

Display & Interaction

• Screen:
  The 5.7 – inch display has a resolution of 720×1520 and a brightness of 450nits. This provides clear visuals in different lighting conditions, whether used indoors or outdoors. The 10 – point touch screen also supports stylus input, enabling precise operation for tasks like data entry and interacting with touch – based applications.
• Touch:
  With 10 – point touch support and stylus compatibility, the SM5 allows for accurate and convenient interaction. This is especially useful when wearing gloves or in situations where a more precise input is required.

Power & Mobility

• Battery:
  • Equipped with a 4000mAh (3.8V) battery. It offers a usage time of about 14 hours (at 50% volume, 60% brightness, playing local 1080P video) and takes 2.5 hours to charge fully with a 5V 2A charger.
• Design:
  Compact and lightweight, measuring 155×77.7×13.3mm and weighing 240±20g. Its portable design makes it easy to carry around, whether in a pocket or attached to a work belt, for use in various mobile work scenarios.

Connectivity & Expansion

• Wireless:
  • WWAN: Supports 4G LTE, 3G WCDMA, and GSM networks, covering a wide range of frequency bands (FDD – LTE, TDD – LTE, WCDMA, GSM). This ensures reliable mobile connectivity across different regions, allowing for seamless communication and data transfer on the go.
  • WiFi: 802.11a/b/g/n/ac wireless technology with 2.4G and 5G support, enabling high – speed wireless networking. This allows users to connect to local networks or create a mobile access point for other devices.
  • Bluetooth 5.0: Allows for seamless pairing with other devices, such as headphones, speakers, or external keyboards.
  • GPS: Incorporates BDS, GPS, and GLONASS, providing accurate positioning for applications like asset tracking, navigation, and location – based services.
  • NFC: 13.56 MHz (PN553 model) enables contactless data transfer and identification, useful for access control and payment – related tasks.
• Wired Interfaces:
  • 1×Type – C (supporting OTG) and either 2×SIM card slots or a SIM + TF card slot.
  • Bottom pogopin connectors offer additional connectivity options for accessories or docking stations.

Durability & Certification

• Rugged Build:
  • IP65 – rated for dustproof and waterproof protection, and can withstand drops of up to 1.5 meters. This makes it suitable for use in harsh industrial environments, construction sites, warehouses, and outdoor settings. It can endure the rigors of daily use in challenging conditions without compromising performance.
  • Operating Temperature: -25°C to 50°C; Storage Temperature: -40°C to 60°C, ensuring reliable performance across a wide range of temperatures.
• Certifications:
  Complies with MIL – STD – 810G, ISO – 9001, and has CE, FCC, 3C certifications, guaranteeing its quality, reliability, and safety. These certifications ensure that the phone meets international standards for durability and performance.

Multimedia & Customization

• Cameras:
  • Front: 5MP camera for video conferencing and self – documentation.
  • Rear: 13MP camera with a flash, suitable for barcode scanning (with optional NLS – N1, M1, or SE2707 scanners), inspection, and general photography.
• Audio:
  An 8Ω 1.0 – watt speaker and a microphone with – 32±2d sensitivity and 2.2kΩx1 output impedance ensure clear audio for communication and media playback. Whether it’s for voice calls or listening to audio instructions, the audio quality is reliable.
• Optional Features:
  • 1D/2D barcode scanner (multiple models available) can be added for specialized industrial applications, such as inventory management and logistics tracking.
  • Customizable buttons (V + -, Power, SOS, Scan, and other customized buttons) offer additional functionality that can be tailored to specific user workflows.

Accessories & Applications

• Included:
  Comes with a box, a 5V 2A charger, and an ejector pin, providing the essential items for immediate use.
• Optional:
  Although not explicitly listed in the original as many optional accessories as some other products, there may be additional accessories available in the market, such as protective cases or car mounts, to further enhance the phone’s functionality and usability.
• Ideal For:
  Ideal for industries such as logistics, field service, and inventory management where durability, long – battery life, and Android compatibility are key requirements. Its rugged design, extensive connectivity, and multiple optional features make it a reliable choice for these applications.
